Description
The pineapple drying machine is to dry the moisture on the surface of the pineapple evenly by certain technical methods. It can realize automatic temperature control and automatic moisture removal, which can keep the dried pineapple in a better shape, maintain the color and shape of the dried pineapple, and improve the product quality. In addition, the use of electric heating can realize automatic temperature control, automatic moisture removal, and adjustable moisture removal speed.
Pineapple Dryer Advantaegs
N0.1 Energy saving
Air energy heat pump drying saves more than half of the electricity consumption compared to traditional electric heating drying equipment.
N0.2 Small footprint
The drying equipment can be installed outdoors or indoors with only a unit and a drying room, which saves a lot of space compared to traditional natural drying.
NO.3 Smart touch screen
Using touch screen programmable control, after setting the corresponding program, there is no need for special personnel to supervise the whole process, saving time and labor.
NO.4 Temperature control
The drying temperature and humidity are controllable, and the color, nutrition, flavor and texture of the dried pineapple remain unchanged, and the quality of the dried pineapple is good.
NO.5 Closed drying room
The whole drying process is completely closed, and the pineapple drying is not in contact with the outside world, which ensures that the heat and air volume in the drying room is not lost, and achieves the effect of energy saving.
NO.6 Dry evenly
The drying room has built-in multiple circulating fans to ensure that the air volume and temperature in the drying room are uniform, the drying effect of the same batch of pineapples is consistent, and there is no dead angle for drying.
Heat Pump Dryer Parameter
| Item | Heat Pump Dryer Parameter | |||
| Model | GG-3P | GG-7P | GG-15P | Unit |
| Environment temperature | -10-43 | -15-43 | -15-43 | ℃ |
| Drying temperature range | 30-75 | 30-75 | 30-75 | ℃ |
| Rated power | 4 | 12 | 21 | Kw |
| Maximum power | 10 | 18 | 33 | Kw |
| Power supply form | 380/3/50 | 380/3/50 | 380/3/50 | V/Ph/Hz |
| Temperature control accuracy | ±1 | ±1 | ±1 | ℃ |
| Electric heating power | 6 | 6 | 12 | Kw |
| Controller | Single chip microcomputer/PLC+color screen control | |||
| Noise level | ≤75 | ≤75 | ≤75 | dB（A） |
| Capacity | 100-200 | 300-700 | 800-1500 | Kg |
| Dehydration capacity | 9 | 21 | 43 | Kg/h（=50℃，80%） |
Pineapple Chips Dehydrator Features
High temperature and high humidity fan
Axial circulation fan accelerates air heat exchange flow and dehumidification is stronger. The motor is all-aluminum and pure copper winding, waterproof and durable;
Automated flow control
The flow control adopts Sanhua electronic expansion valve and four-way valve, which can realize automatic adjustment of flow under cooling and heating state with high reliability and high energy.
Hydrophilic aluminum foil heat exchanger
Its material is anti-corrosion and mildew-resistant, the heat-absorbing area is large, the heating efficiency is higher, and the condensed water on the leather surface hinders the air flow and generates noise.
